UPS
Riello Master HP
Secure your critical infrastructure with the Riello Master HP, a highly efficient and scalable solution designed for maximum power availability and seamless integration into demanding environments.
- Unmatched Scalability and Redundancy.
- Superior Efficiency and Power Quality.
- Advanced Battery Management and Smart Grid Integration.
Model | SKU | kVA | Input Phase | Output Phase | |
---|---|---|---|---|---|
Riello Master HP 100kVA UPS | MHT100 | 100 | Three-phase | Three-phase | |
Riello Master HP 120kVA UPS | MHT150 | 150 | Three-phase | Three-phase | |
Riello Master HP 160kVA UPS | MHT160 | 160 | Three-phase | Three-phase | |
Riello Master HP 200kVA UPS | MHT200 | 200 | Three-phase | Three-phase | |
Riello Master HP 250kVA UPS | MHT250 | 250 | Three-phase | Three-phase | |
Riello Master HP 300kVA UPS | MHT300 | 300 | Three-phase | Three-phase | |
Riello Master HP 400kVA UPS | MHT400 | 400 | Three-phase | Three-phase | |
Riello Master HP 500kVA UPS | MHT500 | 500 | Three-phase | Three-phase | |
Riello Master HP 600kVA UPS | MHT600 | 600 | Three-phase | Three-phase |
Additional Downloads |
---|
Riello Master HP
|
Home Office
Telecommunications
SME Use
Data Centre
Master HP: High-Efficiency, Scalable Power Protection for Critical Applications
Unparalleled Scalability and Redundancy for Growing Demands:
The Riello Master HP UPS is engineered for critical applications, delivering exceptional power availability and efficiency. Its scalable design allows for both distributed and centralised parallel configurations, supporting up to 8 or 7 units respectively. This flexibility provides seamless expansion for increasing power requirements and ensures robust redundancy, safeguarding your critical infrastructure against power disruptions. The Efficiency Control System optimises performance even at partial loads, intelligently managing power distribution among parallel units to maximise overall efficiency.
Superior Power Quality and Advanced Battery Management:
Featuring an integrated output isolation transformer, the Master HP 100kVA provides complete galvanic isolation, ensuring clean and reliable power delivery to sensitive equipment. With an impressive 95.5% efficiency in online mode, energy waste is minimised, reducing operational costs. Advanced battery care features, including Step-Up/Step-Down converters to reduce ripple currents, temperature-compensated charging, and deep discharge protection, extend battery lifespan and enhance reliability. The Smart Active functionality automatically selects the most efficient operating mode based on mains input quality, optimising energy usage and performance.
Smart Grid Integration and Centralised Bypass Options:
Designed for modern power environments, the Master HP 100kVA is Smart Grid-ready, enabling seamless communication with the broader electricity network. For centralised parallel systems, a dedicated static bypass cabinet (MSB) is available, offering centralised control and enhanced system reliability. This comprehensive solution provides a robust, efficient, and scalable power protection system for data centres and other critical industrial environments.
- Choice of 9 power ratings
- 95.5% operating efficiency (ONLINE mode) reduces energy waste
- Parallel up to 8 (distributed) or 7 (centralised) for extra capacity or redundancy
- Efficiency Control System optimises efficiency in parallel installations
- Automatically selects the most efficient operating mode based on the quality of the main
- Ensures galvanic isolation
- Enhanced battery care system ensures maximum battery lifespan
- Step Up/Step Down converter reduces ripple current
- Online Connectivity
- Tower Configuration
Connectivity |
Online |
Configuration | Tower |
Voltage | 380 / 400 / 415 V three-phase |
For a comprehensive breakdown of technical specifications, feature sets and compatibility information for each product variant, please access the dedicated 'Details' tab located adjacent to each listing.
