10Amp Wall Mount 1/1 Phase Automatic Bypass Switch

Part No. APS10/11/AW
APS
APS 10Amp Wall Mount Auto Bypass Switch
APS 10Amp Wall Mount Auto Bypass Switch
/images/gallery/2e1cb6ea6663558ac131-galleryImage.png
/images/gallery/9b0f59b0a4c2db8f7adb-galleryImage.jpg

Please fill out the form below and a member of our team will be in touch.

Join our newsletter
Download PDF
Home Office
Telecommunications
SME Use
Data Center

The Adept Power Solutions external manual bypass switch allows an uninterruptible power supply (UPS) system to be isolated for maintenance or replacement without any disruption to the critical load. This can help avoid costly downtime and maintenance costs.

Our range of external UPS bypass switches, manufactured in-house, have been designed to allow isolation of UPS standby systems for routine servicing, repair or removal without disrupting power to the critical load. All APS bypass switches are provided with a 5 year warranty.

Built to the highest standards using proven components, APS have designed UPS bypass switches are available for single and three phase UPS systems with single or dual input power supplies.

The UPS bypass switch panels can be customised and tailored to specific requirements including the incorporation of distribution boards within the same enclosures.

Picture for illustrative purposes. These bypass have 10Amp IEC Connections only.

  • Auto Changeover
  • Single Phase
  • Wall Mounted
  • 5 Year Warranty
Manufacturer Adept Power Solutions
Power (VA) 1000VA
Input Phase Single
Output Phase Single
Switch Rating (Amps) 10Amps
Weight (Kgs) 4Kgs
Depth (mm) 115mm
Width (mm) 300mm
Height (mm) 180mm
Input Plugs 1 x 10Amp IEC C14
Output Sockets 4 x 10Amp IEC C13
Max Relay Transfer Time 15ms
